Paint Spray Hose 2W

TUEB : Nylon.

REINFORCEMENT : Two layers of high tensile steel wire braided.

COVER : PU .

Temperature Range : -40℃~+100℃ （212°F ）.

APPLICATIONS : Paint spray hose suitable for high pressure airless paint spray systems. Also suitable for applications requiring chemical resistance to solvents and aggressive fluids.

Paint spray hose suitable for high pressure airless paint spray systems. Also suitable for applications requiring chemical resistance to solvents and aggressive fluids.

PAINT SPRAY HOSE 2W
DN	DASH	Hose I.D		O.D	W.P		B.P		B.R	WEIGHT
DN	DASH	inch	mm	mm	psi	mpa	psi	mpa	mm	kg/m
6	-4	1/4″	6.4	13.7	6500	45	26000	180	100	0.336
8	-5	5/16″	8.0	15.2	5800	40	23200	160	110	0.388
10	-6	3/8″	9.5	17.5	5500	38	22000	152	127	0.483
12	-8	1/2″	12.7	21.1	4350	30	17400	120	178	0.605
16	-10	5/8″	16.0	24.8	3000	21	12000	84	203	0.803
19	-12	3/4″	19.0	28.6	2300	16	9200	64	250	0.922
25	-16	1″	25.4	34.5	2175	15	8700	60	305	1.092

NOTE : Any color cover will available as requirement. Any questions please feel free to contact us.

SWICO TECHNOLOGY produce SAE standards hydraulic hoses, DIN standards hydraulic hose and industrial hose, including super high pressure rubber hose, high pressure rubber hose, low pressure rubber hose, CNG hose, LPG hose, large diameter PTFE hose, oil hose, air hose, water hose, large diameter oil suction and discharge hose, large diameter water suction and discharge hose, chemical hose, mining hose, concrete delivery hose etc. All cilients will get satisfying service and products from us.
